| SMI-MA Facility List |
| CNC Machining Centers |
| 1 |
Kiwa KNH-400 Horizontal Machining Center
Pallet changer with 2 pallets Spindle |
Spindle: 20 HP, 8,000 rpm
Capacity: 23.6"(x), 23.6"(y), 20"(z)
Atc: 64 tools
Control: FANUC |
| 2 |
Kiwa Mach 4 Horizontal Machining Centers
Pallet changer with 2 pallets Spindle |
Spindle: 20 HP, 8,000 rpm
Capacity: 22"(x), 20"(y), 21"(z)
Atc: 32 tools
Control: FANUC |
| 5 |
Saeilo Mach 3A Horizontal Machining Centers
Pallet changer with 2 pallets Spindle |
Spindle: 10 HP, 10,000 rpm
Capacity: 16"(x), 14"(y), 16"(z)
Atc: 20 tools
Control: FANUC |
| 1 |
Shizuoka Vertical Machining Center Spindle |
Spindle: 15 HP, 5,000 rpm
Capacity: 59"(x), 30"(y), 28"(z)
Atc: 24 tools
Control: FANUC |
| 1 |
Tongil TNV-80A HS Vertical Machining Center Spindle |
Spindle: 24 HP, 8,000 rpm
Capacity: 30"(x), 16"(y), 15"(z)
Atc: 30 tools
Control: FANUC |
| 2 |
Tongil TNV-80A Vertical Machining Centers Spindle |
Spindle: 24 HP, 6,000 rpm
Capacity: 32"(x), 19"(y), 20"(z)
Atc: 20 to 30 tools
Control: FANUC |
| 5 |
Tongil TNV-40 Vertical Machining Centers Spindle |
Spindle: 10 HP, 6,000 rpm
Capacity: 22"(x), 16"(y), 20"(z)
Atc: 16 tools
Control: FANUC |
| CNC Turning Centers |
| 1 |
Tongil TNL-60 CNC Lathe |
Spindle: 25 HP, 1,300~3,200 rpm
Swing over bed: 23.6"
Atc: 12 tools
Control: FANUC |
| CNC Programming |
| 2 |
TEKSOFT, PRO-CAD/CAM SYSTEM, version 9.0 |
Features:
3-D "Surfacing" for Milling
Down / Up loading programs to machines
Via direct RS-232 hook-up |
| Calibrated Inspection Equipment |
| 1 |
Brown & Sharp Coordinate Measuring Machine |
30"(x), 26"(y), 20"(z), .00002" Res |
| 2 |
Brown & Sharp Coordinate Measuring Machine |
14"(x), 16"(y), 12"(z), .00002" Res |
| Support Equipment |
| 2 |
NIKKEN 10" 4th AXIS |
|
| 2 |
Bridgeport Milling Machines |
1 HP, 25"(x), 14"(y), 14"(z) |
| 1 |
TOS TRENCIN SN |
10 HP, 16" Swing 40" Center |
| 2 |
Drill Press |
0.5 HP |
| 1 |
Horizontal Saw |
0.75 HP |
| 1 |
Vertical Saw |
1 HP |
| 1 |
DAREX, Drill Sharpener |
|
| 1 |
ACER, Surface Grinder |
2 HP, 6"x22" |
| 1 |
MILLER, CP-200 Constant DC Arc Welder |
|
| 1 |
MILLER, TIG Welder |
|
| 1 |
Big, High Spindle Speeder |
24,000 rpm |
| 1 |
Tumbling Machine |
|
| 2 |
Sand Blasting Machine |
24"x36"x22" |
| 1 |
Starrett Rapid Check II Programmable Coordinate Measuring Machine |
23"(x), 25"(y), 17"(z), .00002" Res |
| 1 |
Brown & Sharp Coordinate Measuring Machine |
30"(x), 26"(y), 20"(z), .00002" Res |
| 1 |
Brown & Sharp Coordinate Measuring Machine |
14"(x), 16"(y), 12"(z), .00002" Res |
