| SMI-CA Facility List |
| CNC Machining Centers |
| 2 |
Mori Seiki SH-400 Horizontal Machining Center
Pallet changer with 2 pallets |
Spindle: 30HP, 12,000 rpm
ATC: 60 tools
Capacity: 22.0"(x), 20.1"(y), 20.1"(z)
Control: Fanuc 18M |
| 1 |
Mori Seiki SV-500 Vertical Machining Center
Pallet changer with 2 pallets |
Spindle: 30HP, 10,000 rpm
ATC: 30 tools
Capacity: 30.1"(x), 20.1"(y), 20.1"(z)
Control: Fanuc 18M |
| 2 |
Saeilo Mach 4 Horizontal Machining Centers
Pallet changer with 2 pallets |
Spindle: 20 HP, 8,000 rpm
Capacity: 23"(x), 17"(y), 19"(z)
Atc: 56 tools
Control: FANUC 21-M |
| 2 |
Saeilo Mach 3 Horizontal Machining Centers
Pallet changer with 2 pallets |
Spindle: 10 HP, 6,000 rpm
Capacity: 16"(x), 14"(y), 16"(z)
Atc: 20 tools
Control: FANUC OM-C |
| 1 |
Saeilo MAGNUM 75VS Vertical Machining Center |
Spindle: 20 HP, 5,000 rpm
Capacity: 67"(x), 30"(y), 26"(z)
Atc: 24 tools
Control: Mitsubishi 520-A |
| 2 |
Tongil TNV-80 Machining Centers |
Spindle: 24 HP, 5,000 rpm
Capacity: 30"(x), 16"(y), 15"(z)
Atc: 30 tools
Control: FANUC 11-MA |
| 1 |
Tongil TNV-80 HS Machining Center |
Spindle: 24 HP, 8,000 rpm
Capacity: 30"(x), 16"(y), 15"(z)
Atc: 30 tools
Control: FANUC OM-C |
| 3 |
Tongil TNV-40A Machining Centers |
Spindle: 10 HP, 6,000 rpm
Capacity: 22"(x), 16"(y), 15"(z)
Atc: 16 tools
Control: FANUC OM-C |
| CNC Turning Centers |
| 1 |
Tongil TNL-60 Slant-Bed Turning Center |
Spindle: 25 HP, 3 Speed, 3,500 rpm
Turret: 12 tools
Max turning dia x length: 12"x24"
Control: FANUC O-TC |
| 2 |
Tongil MAGNUM T-8 Slant-Bed Turning Centers |
Spindle: 20 HP, 4,500 rpm
Turret: 12 tools, both I.D. or O.D.,
widely spaced.
Max turning dia x length: 12"x15"
Control: FANUC O-TC |
| CNC Programming |
| 1 |
SolidEdge/Esprit CAD/CAM System |
|
| 2 |
TEKSOFT, PRO-CAD/CAM SYSTEM, version 8.0 |
Features:
Full 3-D "Surfacing" capability for Milling, 2-D turning, Download to machine control via direct RS-232 hook-up. |
| Calibrated Inspection Equipment |
| 2 |
Brown & Sharp Coordinate Measuring Machine |
14"(x), 16"(y), 12"(z), .0002" Res |
| 1 |
Micro-View Optical Comparator |
12" Dia |
| 1 |
Mitutoyo Height Master |
0.5"~12.0", .0001" Res |
| 1 |
Mitutoyo Surf Test-211 |
|
| 1 |
Mitutoyo Gage Block Set |
81 Pcs., Grade B |
| 2 |
HDT Gage Block Set |
81 Pcs., Grade B |
| 4 |
Mitutoyo Dial Height Gage |
0"~12", .001" Res |
| 1 |
Mitutoyo Dial Height Gage |
0"~18", .001" Res |
| 1 |
Mitutoyo Micrometer Set |
0"~6", .0001" Res |
| 1 |
Starret Micrometer Set |
0"~6", .001" Res |
| 9 |
Mitutoyo Bore Gage |
0.24"~6.0", .0001" Res |
| 1 |
NCK Dial Caliper Gage |
1.875"~2.875", .001" Res |
| 1 |
SPI Dial Caliper Gage |
0.2"~0.6", .0005" Res |
| Support Equipment |
| 3 |
Bridgeport-Type Vertical Mills |
|
| 1 |
Drill Press |
|
| 1 |
Tongil TIPL-4 Engine Lathe |
16"x40" |
| 1 |
Vertical Band Saw |
|
| 1 |
Horizontal Production Saw |
6" capacity |
| 1 |
Drill Sharpener |
|
| 1 |
10-Ton Hydraulic Press |
|
